Product Details
| Model | ZZ1127G4715C1R | |
| Engine | Manufacture: YUCHAI Diesel: 4-stroke direct injection diesel engine Model: YC4E140-33, Euro II emission standard 4-cylinder in-line with water cooling, turbo-charging and intercooling Maximum output: 140 HP (105 Kw) @ 2800 rpm according to DIN Maximum torque: 500 Nm @ 1600 rpm Number of cylinder: 4 Displacement: 4.257L Bore: 110mm Stroke: 112mm Compression ratio: 17.2hp/L | |
| Clutch | Single plate dry diaphragm spring clutch, diameter 380mm, hydraulically operating | |
| Transmission | WLY Transmission, model WLY6T51, synchromesh, 6 forward & 1 reverse | |
| Front Axle | Forging forming of front axle l-beam, to guarantee the stiffness and high strength, 3.2T | |
| Rear Axles | Mature punching welding axle and pressed axle housing, 8T Ratio: 5.286 | |
| Chassis | Frame: Ladder frame with section of 195 X 65 X 6 mm , all cold riveted cross members Front suspension: 9 leaf springs, shock absorbers and stabilizer Rear suspension: 12 main leaf springs + 9 leaf springs Spare wheel carrier: with one spare wheel Fuel tank: 220 L | |
| Steering | Hydraulic steering with power assistance Ratio: 18.85 : 1 | |
| Brakes | Service brake: dual circuit compressed air brake Parking brake (Emergency brake): spring energy, compressed air operating on rear wheels (optional) | |
| Tyre | 8.25R20 TUBE | |
| Cab | Single cab with one sleeper, 45°hydraulically tilt able to the front, 2-arm windscreen wiper system with three speeds, adjustable driver’s seat, with heating and ventilation system, interior double sun visor, sunroof, radio and USB interface, safety belts, adjustable steering wheel, horn. | |
| Electrics | Operating voltage: 24V, negative grounded Starter: 24V, 3.6KW Batteries: 24V, 120Ah Horn, headlamps, fog lights, indicators and reverse light | |
| Instrument Panel | Active central controller with indicators, integrating daily check on-board. Combined indicators of compressed air pressure, coolant temperature, engine oil pressure, etc. | |
| Dimensions in mm | Wheelbase Front wheel track Rear wheel track Front overhang Rear overhang Approach angle Departure angle Overall dimension Body size | 4700 1798 1764 1240 2505 27° 16° 8445 X 2400 X 2650 6250 X 2300 X550 |
| Weight in kg | Payload Dead weight Gross vehicle weight | 8000 5300 12490 |
| Performance | Maximum speed Maximum grade ability Minimum ground clearance | 95 km/h 25% 210 mm |
Weights, dimensions and features are given for reference and may be modified according to the choice of certain options. The manufacturer reserves the right to modify the above specifications without prior notification.
